4 Setup
Operator’s Manual 4 - 5
4.1.4 Application
Set the measurement ruler, measurement setting, follicle method, left ventricular setting, comment
setting and so on.
Measure Parameter
Controls are as follows:
LV Cube/Teichholz/Gibsom
Set the tools used in the Cube/Teichholz/Gibson study.
Comment
Set whether to clear comments and bodymark:
Tissue
Tracking QA
Segment Model To set the cardiac segment model: 16 or 17.
Parameter
Display
Image Parameter
Display
To select the parameters under each mode to be displayed in
the real-time imaging screen.
ZoneVue ZoneVue Turn on/off ZoneVue.
Type Item Description
Item Description
Cursor Type Type of cursor displayed on the measurement caliper and results window.
Value options:
• Number: the cursor always displays as “+” while different measurements
are marked with numbers.
• Symbol: the cursor displays sequentially in 8 symbols to identify different
measurements.
Cursor Size The size of the cursor.
HeartBeat The number of cardiac cycles in the heart rate calculation. (In heart rate
measurement, the number of cardiac cycles should match the preset number.)
Cursor Line
Display
If unselected, the connecting line between the measuring ends will be hidden
after measurement.
Ellipse Cross Line
Display
If unselected, the measuring axis within the ellipse area will be hidden after
measurement.
Clear results while
deleting caliper
Uncheck. The image is unfrozen or the image mode is changed after the
measurement is completed. The measurement results are saved if the caliper
is cleared.
Unit Settings To set the measurement unit.
Item Description
Clear comments while unfreezing
image or changing probe/exam
To set whether to clear comments while unfreezing image or
changing probe/exam.
Clear Bodymark upon unfreeze To set whether to clear bodymark whiling unfreezing image.
Voice comment enabled To set whether to enable voice comment feature.
