Operator’s Manual 4 - 1
4 Setup
The Setup function is designed to set the configuration parameters of operating the system and
maintaining user workflow setup data. The setup data of the user and system are stored to the hard
drive, and should be backed up to CD/DVD or USB memory device.
CAUTION
When the preset data is changed, be sure to save the preset data according to
the methods described in this chapter. Mindray is not responsible for the loss of
preset data.
• To enter Setup:
– In B mode, click > [Setup] on the touch screen.
– Press the user-defined <Setup> key to enter the setup menu.
• To exit Setup:
– Select [OK] in the Setup menu. The parameter settings are saved.
– Select [Cancel] in the Setup menu or press <Esc> to close the Setup menu.
4.1 System Preset
The system automatically enters the [System] screen after you enter Setup.
Item Description
Region To set the hospital name, language, time zone, time format and system
date/time.
General To set patient information, exam setup, patient management, storage,
system dormancy, display and so on.
Image To set general parameters in imaging modes.
Application To set the measurement ruler, measurement setting, follicle method,
comment setting and so on.
OB To set the relevant information regarding the fetal gestational age, fetal
growth formula and fetal weight.
Console&Footswitch To assign functions to the foot switch and user-defined keys.
Key Board To assign functions to the F keys of the key board.
NOTE:
The setup page is available only when a QWERTY keyboard is
configured.
Gesture Preset the gesture on the touch screen.
Output Set the output format, the range and the resolution for the image.
