6-4
6 6802-30-66680 Power switch & LED board 1
7 115-004219-00
Button board
1
8 M04-003105--- Tapping screw PT3×8 3
9 M04-004012--- Crosshead screw M3×6 16
10
6802-30-66901 or
6802-30-66772(optional)
12.1" LCD assembly (anti-glare screen) 1
11 0000-10-10996
Spring
1
12 042-002757-00 Front housing bracket 1
13 0000-10-10789 Optical Encoder 16 steps 5VDC Dip6 1
14 042-000693-00
Encoder mounting board
1
15 6802-20-66729 Heat conductor for the LED cover 1
16 M04-051003--- Crosshead tapping screw PT2×6 2
17 6802-30-66682 LED board 1
18 6802-20-66690 Light conduction block 2 1
19 6802-20-66689 Light conduction block 1 1
20 6802-20-66688 Alarm LED cover 1
21 M6T-040001--- Clamp spring.1707P 1
