6-14
6.4.4 Interface Board Assembly
6.4.4.1 Interface Board Assembly (6802-30-66769)
Parts List
SN
P/N
Description
Qty
1
042-000059-00
Interfa
ce board frame (new in
terface)
1
2 M6T
-03
0006---
Leaf
3
3
M04-051045---
Crosshead screw M2.5×
6
2
4
051-0000
20-00
USB_Hub b
oard (no anal
og output)
1
5
047-000
128-00
Interface board in
sulating plate
1
6
M04-004012---
Crosshead screw M3×6
4
7
051-00001
9-00
DVI interface
board (can supp
ort IABP)
1
139
141
