Mindray DPM 6 - CCO Module

6-43
15 6800-20-50278 Snap plate 1
16 6800-20-50338 Waterproof seal 01 1
17 6800-20-50292 Fixer 2
18 6800-30-50806 Oridion CO
2
module infrared communication board 1
19 M04-011002--- M3 nut with spring washer 2
20 6800-20-50270 Single-slot module inner housing, right side 1
21 9201-30-35959 microstream CO
2
module connector 1
22 M04-005005--- Crosshead screw M3×6 1
23 M04-003105--- Tapping screw PT3×8 2
24 6800-20-50286 Locking device 1
25 9201-20-36010 Torsion spring washer 1
26 6800-20-50394 Snap close 1
27 9201-20-35961 Torsion spring for microstream CO
2
connector 1
6.6.11 CCO Module
Exploded View
