Mindray DPM 6 - LCD with Touchscreen

6-5
6.3.2 12.1” LCD with Touchscreen
Exploded View
Parts List
SN P/N Description Qty
1
043-000487-01 or
* 043-000490-01
Front bezel (DPM6) (mold MR66687)
Front bezel (DPM6/basic)
1
2 M6G-020015--- Hose 1
3 0651-20-76735 Knob encoder (mold MR76734) 1
4 6800-20-50198 Key pad 1
5 6802-20-66691-51 Power button (DPM6) 1
6 6802-30-66680 Power switch & LED board 1
7 115-004220-00
Button board (AU 12.1” screen G121SN01 +
touchscreen)
1
8 M04-003105--- Tapping screw PT3×8 3
