5-11
2.
Unplug the cables respectively from
the
button board and the LCD to the backlig
ht
board. The
n, unscr
ew the two M
3
×
6 screws to remove the inverter
.
5.3.8 Removing the LCD
CAUTION
z
Do not touch the LCD.
z
Disassemble the LCD in an environment as dust-free as possible.
1.
Unsc
rew the eight M3
×
6 screws and rem
ove the LCD with c
are. Do not
touch the
LCD
surface and prevent it from being contaminated by dust.
