Mindray DPM 6 Service Manual

6-27
16 M04-004012--- Crosshead screw M3×6 6
17 M04-000306--- Stud screw M3×10+8-8 coated with antirust nickel 1
18 6800-30-50075 Nios II module 1
6.6 Parameter Modules
6.6.1 MPM Module
Exploded View
Parts List
SN P/N Description Qty
1 6800-20-50278 Snap plate 2
2 6800-20-50293 Screw 2
3 6800-20-50279 Infrared light filter 1
4 M04-000104--- Spring washer 2
5 6800-20-50273 2-slot module rear housing 1
6 6800-20-50339 Waterproof seal 02 1
7 6800-30-50684 MPM infrared communication backboard 1
