Mindray DPM 6 Service Manual

6-30
SN P/N Description Qty
17 801-6800-00211-00 NIBP pump for M51A and iPM 1
18 S1-0103-00-0511 Tee connector, White, Nylon 3
19 0010-10-12408 Inline Filter 2
20 082-000098-00 630F Reducer 1
21 082-000864-00 Valve 1
22 M04-005005--- Flat head screw, Phillips M3×6 2
23 6800-20-50278 Spanner 2
24 M04-000104--- Spring Washer 2
25 6800-20-50293 Screw 2
26 6800-20-50279 Infrared light filter 1
27 6800-20-50273 Rear cover 1
28 049-000328-00 Silicone tee tube 1
29 M90-100028-01 Connector 1
30 009-002220-00 Cable for infrared Communication board 1
6.6.3 C.O. Module
Exploded View
