3-22
3.4.11 ICG Test
Tool required:
ICG simulator (BZ-4575)
BioZ Dx patient cable (PN: 040-000543-00）
BioZ Dx lead wire (PN: 040-000544-00)
1. Connect the ICG simulator and the patient monitor using ICG patient cable and lead
wire.
2. Select [ICG setup]→ [Patient Demographics >>] and then input parameter values as
follows:
Height 180 cm CVP 6 mmHg
Weight 75 kg PAmean 8 mmHg
PAWP 10 mmHg
3. Switch on the simulator and set as follows: HR=60±1 bpm, VI=61±4/1000s,
TFC=32±2/kOhms. Then, start ICG monitoring.
4. After the measurement becomes stable and check that the measured results are as
follows: HR=60±2 bpm, VI=61±4/1000s, TFC=32±2/kOhms.
5. Set on the simulator as follows: HR=70±1 bpm, VI=48±4 /1000s, TFC=32±2 / kOhms,
and then start ICG monitoring. After the measurement becomes stable and check that the
measured results are as follows: HR=70±2 bpm, VI=48±4 /1000s, TFC=32±2 / kOhms.
3.4.12 BIS Test
You can choose either of the following methods to perform the test:
Method 1:
Tools required:
BIS cable (PN: 6800-30-50761）
BIS sensor (PN: 0010-10-42672)
1. Connect the BIS sensor to a healthy, wide-awake adult as directed in the Operator’s
Manual.
2. Check the EEG wave and BIS numerics displayed on the screen and make sure the BIS
value is within 80-100.
