5-13
5.3.10 Removing
the Fan Assembl
y
Unplug the
cable that
connects th
e fan assem
bly and the m
other board.
Then, unsc
rew the
four M3
×
6 screws and
remove the fa
n assembly.
5.3.11 Removin
g Battery Compartment Assembly
1.
Unplug the cable that connect
s the battery compartment asse
mbly and the m
other board.
Then, unsc
rew the three M3
×
6 screws and tak
e out the ba
ttery compartment asse
mbly.
Heat conducting glue
92
94
