5-9
5.3.5 Removing the Button Board
1.
Disconnect the cables from
the button b
oard to the alarm
LED board, backlight
board
and touchscreen
control board.
2.
Remove the grounding sp
ring and then unscrew the thr
ee PT3
×
8 screws and take out
the button board.
NOTE
z
Do not forge
t the grounding sprin
g when reasse
mbling..
88
