6-21
6.4.9 CF Card Assembly
CF Car
d Assembly (11
5-001906
-00)
Parts List
SN
P/N
Description
Qty
1 6802-20-
66725
Card
cover
1
2 6802-20-
66726
CF
card
board
fixture
1
3 M6T
-030005---
Leaf,
178S3
0(1EA=406mm)
2
4
M39-0002
34---
Ejector for CF card s
ocket (50pin)
1
5
M04-002505---
Crosshead screw M3×6
4
6
M04-051
137---
Crosshead screw
M2×4
4
7 042-00
0317-00
CF
card
shield
1
8
051-00010
4-00
9211 CF card
board (shield can
be installed)
1
9 6802-20-
66674
WLAN
overlay
1
146
148
