6-22
CF Card Sl
ot Cover Ki
t
（
6812
-30-669
95
）
Parts List
SN
P/N
Description
Qty
1 047-000731-00
Cover
overlay
1
2 6802-20-
66725
Card
cover
1
3 6802-20-
66726
CF
card
board
fixture
1
4 M6T
-030005---
Leaf,
178S3
0(1EA=406mm)
2
5
M04-002505---
Crosshead screw M3×6
2
147
149
