6-11
Parts List
SN P/N Description Qty
1 6802-30-66768 Fan assembly 1
2 6802-30-66765 Integral module rack 1
3 115-003229-00 Main support assembly 1
4 6802-30-66766 Rear housing assembly 1
5 6802-30-66770 Power module assembly 1
6 M04-051014--- Crosshead screw M3×12 4
7
043-000059-00 or
*6812-20-67000-51
or 043-000472-00
Interface board cover(new interface)
Interface board cover (basic)
Interface board cover
1
8 6802-20-66707-51 CF card door 1
9 TR6F-30-67306 TR6F recorder 1
10
6802-30-66769 or
*6812-30-66994 or
115-003230-00
Interface board assembly
1
11 M04-004012--- Crosshead screw M3×6 22
12 6802-30-66763 Battery compartment assembly 1
13 115-003228-00 6802 internal wireless AP assembly 1
14
6802-30-66767 or
*6812-30-66993 or
115-003231-00
Master control board assembly 1
15
115-001906-00 or
*6812-30-66995
6802 CF card assembly (211 driving board)
CF card slot cover kit
1
16 M04-004015--- Crosshead screw M3×8 7
To Next Page
