6-16
6.4.4.3 Interface Board Assembly
（
115-003230-00
）
Part List
SN
P/N
Description
Qty
1
042-000059-00
Interfa
ce board frame (new in
terface)
1
2 M6T
-03
0006---
Leaf
3
3
051-0000
20-00
USB_Hub b
oard (no anal
og output)
1
4
047-000
128-00
Interface board in
sulating plate
1
5
M04-0040
12---
Cross pan head scr
ew with washer
M3×6
4
6
051-00001
9-01
DVI interface
board (S
tandard configurat
ion)
1
141
143
