5-15
2.
Disconnect the cable that connects
the MPM module rack comm
unication board an
d the
3-slot module rack commun
ication board. Release the two snaps and unplu
g the NiosII
module on
the 3-slot module
rack.
3.
Unsc
rew the eight M3
×
6 screws and then rem
ove the 3-slot modul
e rack
communication board and MPM m
odul
e rack communication board.
NOTE
z
Do not forge
t the grounding sprin
g when reasse
mbling..
NiosII module
94
96
