5-19
5.3.14
.2 Remov
ing the ex
ternal wi
reless AP
1.
Disconnect the netw
ork cable and the
power cord
2.
Press the leaf on the fix board w
ith forceps; push the AP
and installation board
upwards.
Then remove the AP and installation bo
ard.
3.
Unscrew the two M3
×
8 screws and tak
e out the fix
board.
Press the leaf with a
forceps
Insta
llati
on boa
rd
98
100
