10-14 System Diagnosis and Support
[Default] The system performs item tests by clicking it.
[Select All] Select all test items by clicking it.
[Select None] Cancel the test item by clicking it.
[Continue/Stop] One button for two operations [Continue] and [Stop]. If you click [Continue],
the test continues even though a test item fails during the test; however if
you click [Stop], the test stops once a test item fails during the test.
[Start] Click to perform tests for checked items one by one while the button turns to
[Stop]. During the test, if you click [Stop], the test stops. After the test is
completed, the [Stop] button turns to [Start], and waits for the next test.
[Next Fail] After completing the test, click [Next Fail]. The program searches for the
failed test item from message list, and rearrange it to the top of the test
information list. If the program reaches the bottom, it starts to search from
the top of the list again.
[Clear History] Click to clear off the test data in Testitems and Messages and to initialize the
system structure diagram to original status.
[Loops] It is used to perform loop test. Select the check box and type the times for
loop test in the box on the right of screen, and perform the test according to
the times typed. If the loop times are less than 0, it continues the loop test
before the user stops it or encounters the error.
[Save Report] The dialog box to remind the user of exporting the report appears by clicking
the button. Plug the removable storage device, and select corresponding
logic drive, and then click [OK]. The test data is saved to the selected root
directory. The button is disabled if the removable storage device is not
plugged in.
[Shut Down] Close the program, and shut down the device. The system reminds the user
of saving the test report to removable storage device when shutting down the
device.
Remarks: the test item includes parent-test item according to the board from the test area. There
are sub-test items belonging to parent test item. It can be customized according to the requirement.
If the test item is ticked (
), this item is in the test list; otherwise, this item is not in the test list.
When a parent item is selected, all the sub items of this item are selected by default; otherwise,
when deselecting a parent item, all the sub items of this item are deselected by default.
Description:
The user can see production, maintenance and user self-test interface from the screen. The
production and maintenance self-test interfaces can be divided into five areas.
