Passport V Operating Instructions 0070- 0-0704-02 5 - 3
Respiration Monitoring Resp Menu
5.3 Resp Menu
To display the Resp Menu:
On the normal screen:
Select Parameters 〉 Resp
or
Select the ECG tile
〉 Resp Menu
or
Select the Resp tile
FIGURE 5-3 Respiration Menu
Resp Menu
MENU ITEM SELECTIONS COMMENTS
Normal Screen — Select to return to Normal Screen (or press the
Normal Screen key on the front panel).
Resp Lead I
II (default)
Select to change respiration lead for ECG.
When the current Resp Lead drops, the Resp
waveform will be a straight line.
Resp On (default)
Off
Select to turn respiration on or off.
On: Opens the Resp Module to start respiratory
measurement.
Off: Closes the Resp Module to stop respiratory
measurement. Displays "OFF" in Resp numeric tile.
