Mindray Passport V Operating Instructions

Technical Alarm Messages Messages
14 - 4 0070- 0-0704-02 Passport V Operating Instructions
14.2 Technical Alarm Messages
14.2.1 ECG Alert Message
14.2.2 RESP Alert Message
ALARM MESSAGE PRIORITY REASON SOLUTION
LA Lead Off 3 LA lead off the
patient.
Connect lead wires.
LL Lead Off 3 LL lead off the patient. Connect lead wires.
RA Lead Off 3 RA lead off the
patient.
Connect lead wires.
V Lead Off 3 V lead off the patient. Connect lead wires.
C Lead Off 3 C lead off the patient. Connect lead wires.
F Lead Off 3 F lead off the patient. Connect lead wires.
L Lead Off 3 L lead off the patient. Connect lead wires.
R Lead Off 3 R lead off the patient. Connect lead wires.
ECG Noise 3 External interference.
Patient movement.
Check patient
Check Electrode Contacts /
reposition electrodes /cable.
Check environment for source
of interference.
ECG Artifact 3 External Interference
Patient movement.
Check patient
Check Electrode Contacts /
reposition electrodes /cable.
Check environment for source
of interference.
HR Overrange 3 Heart rate outside of
measureable range
Check patient.
ST-<X> Overrange 3 ST deviation outside
of measureable
range.
Check patient.
ECG Weak Signal 3 ECG signals are too
weak to be analyzed.
Check ECG leads to see if
there is good contact between
the leads and the patients
skin.
ALARM MESSAGE PRIORITY REASON SOLUTION
CVA 3 Can be caused by
shallow breathing or
an apnea event.
Patient HR and
respiratory rate
identical.
Check the patient.
Adjust scales or leads if
necessary.
