Passport V Operating Instructions 0070- 0-0704-02 19 - 13

Appendix Performance Characteristics

19.8.3 IBP

Regulations

EN60601-2-34 / IEC60601-2-34:2000

Function and Specifications

• Measured Parameters: Systolic pressure, diastolic pressure, means pressure, PR

• Intended Patient: Adult, Pediatric, Neonatal

• Measurement Method: Direct invasive measurement

• Pressure label (default: Art and CVP):

• Pressure Unit: mmHg

• Calibration Accuracy Range: ± 200 mmHg

• Calibration Accuracy: ± 1 mmHg

• RTI: <0.5 mmHg RTI, 300 Ohm source resistance

• Drift: <0.15 mmHg/ºC; less than ± 1 mmHg within 24 hours

• Pressure Transducer:

• Excitation voltage: 5VDC, ±2%

• Sensitivity: 5 uV/mmHg/Volt

• Resistance range: From 300 to 3000 ohms

• Volume displacement in mm

/100 mm Hg may be provided in the transducer

Instructions For Use.

• supplied with the EQUIPMENT.

• Pressure Calibration: Supported

• Pressure Measurement specifications:

• Measurement range: From -50 to +300 mmHg

• ART, UA: From 0 to 300 (mmHg)

• PA: From-6 to 120 (mmHg)

• CVP: From -10 to 40 (mmHg)

• RA, LA, ICP: From -10 to 40 (mmHg)

• LV: From 0 to 60 (mmHg)

• P1~P2: From -50 to 300 (mmHg) (Accuracy: 2% or 1mmHg, whichever is greater

(excluding errors caused by a transducer); Resolution:1 mmHg)

Art Arterial pressure PA Pulmonary artery

CVP Central venous pressure RA Right atrial pressure

ICP Intracranial pressure LA Left artrial pressure

LV Left ventricular pressure UA Umbilical arterial pressure

P1~P2 Unspecified pressure labels
