Performance Characteristics Appendix
19 - 18 0070- 0-0704-02 Passport V Operating Instructions
Masimo SET
®
Reference notes
The Masimo SET MS-3 pulse oximeter with LNOP
®
•Adt sensors has been validated for no
motion accuracy in human blood studies on healthy adult volunteers in induced hypoxia
studies in the range of 70% to 100% SpO
2
against a laboratory co-oximeter and ECG
monitor. This variation equals plus or minus one standard deviation. Plus or minus one
standard deviation encompasses 68% of the population.
The Masimo SET MS-3 pulse oximeter with LNOP
®
•Adt sensors has been validated for
motion accuracy in human blood studies on healthy adult volunteers in induced hypoxia
studies while performing rubbing and tapping motions at 2 to 4 Hz. At an amplitude of 1 to
2 cm and non-repetitive motion between 1 to 5 Hz. At an amplitude of 2 to 3 cm in induced
hypoxia studies in the range of 70% to 100% SpO
2
against a laboratory co-oximeter and
ECG monitor. This variation equals plus or minus one standard deviation. Plus or minus one
standard deviation encompasses 68% of the population.
The Masimo SET MS-3 pulse oximeter with LNOP
®
•Neo and Neo•Pt sensors has been
validated for neonatal motion accuracy in human blood studies on neonates while moving
the neonate's foot at 2 to 4 Hz at an amplitude of 1 to 2 cm against a laboratory co-oximeter
and ECG monitor. This variation equals plus or minus one standard deviation. Plus or minus
one standard deviation encompasses 68% of the population.
The Masimo SET MS-3 pulse oximeter has been validated for low perfusion accuracy in
bench top testing against a Biotek Index 2 simulator and Masimo's simulator with signal
strengths of greater then 0.02% and a % transmission of greater than 5% for saturation's
ranging from 70 to 100%. This variation equals plus or minus one standard deviation. Plus
or minus on standard deviation encompasses 68% of the population.
Low Perfusion Performance
LOW PERFUSION CONDITIONS
PULSE
AMPLITUDE
%
TRANSMISSION
SATURATION
ACCURACY
PULSE RATE
ACCURACY
> 0.02% > 5% ± 2 digits ± 3 digits
Pulse Rate Range and Accuracy
ACCURACY
PATIENT SIZE
PULSE RATE
RANGE
NO MOTION
CONDITIONS
DURING
MOTION
CONDITIONS
Adult / Pediatric / Neonate 25 to 240 bpm ± 3 digits ± 5 digits
