ECG Monitoring Menus: ECG Main and Submenus
ECG Menu
MENU ITEM SELECTIONS COMMENTS
Normal Screen — Select to return to Normal Screen (or press the
Normal Screen key on the front panel).
ECG 1
ECG 2
ECG 3
ECG 4
ECG 5
ECG 6
For 3-lead leadset:
I, II, III
For 5-lead leadset:
I, II, III, aVR, aVL,
aVF, V
Defaults:
ECG 1 = II
ECG 2 = I
ECG 3 = V
ECG 4 = aVR
ECG 5 = aVL
ECG 6 = aVF
Select to change ECG lead to be analyzed.
When a 3-lead configuration is detected, only ECG1
is displayed.
When a 5-lead configuration is detected, ECG1 to
ECG6 can be displayed.
In Normal screen, the ECG lead displayed can be
selected as required.
In All ECG View, the ECG1 to ECG6 options can
be selected as required.
The effect of 3-lead and 5-lead switchover:
5-lead to 3-lead: If ECG1 is I/II/III, then ECG1 is
unchanged. Otherwise, automatically change to II.
3-lead to 5-lead: ECG1to ECG6 are unchanged from
the previous 5-lead setting.
Speed
6.25 mm/s
12.5 mm/s
25 mm/s (default)
50 mm/s
Select to change the trace speed (mm/s) of the ECG
waveform. Applies to all ECG leads.
Arrhythmia Menu Select to open the Arrhythmia Menu.
Available only if Arrhythmia option is installed.
Disabled if Patient Size = Neonate.
ST Menu Select to open the ST Menu.
Available only if ST option is installed.
Disabled if Patient Size = Neonate.
Relearn — Select to manually initiate the relearning process for
ST Measurements or Arrhythmia Analysis.
Relearn is disabled if at least one of the following:
• Patient Size = Neonate.
• ST Analysis and Arrhythmia = Off.
• ST Analysis and Arrhythmia are not configured.
After relearning is started, arrhythmia relearning and
ST relearning are performed simultaneously. The
arrhythmia and ST analysis templates are recreated
and the message “Relearning...” is displayed. During
relearning, ST and PVCs are displayed as “– – –“.
Arrhythmia relearning should be automatically
started when:
• Lead type is changed.
• ECG lead wires are reconnected to the patient.
• Analysis lead is changed.
• Patient size is changed.
• Arrhythmia analysis is turned on.
• Module is turned on.
• Exiting Standby mode.
