23
Please press the key when the compensation of
each point is completed.
is displayed.
Press the key to complete the digital linearization
mode.
is displayed, and the setting data is
memorized in the internal memory.
Please set to the stand-by condition by
pressing the key.
The digital linearization mode is finished.
Please make the weights to be compensated as .
The linearizating compensation cannot be executed over the maximum capacity.
The compensation data of the digital linearization can be cleared by C function CF-98.
Please refer to the paragraph 6-11. Digital linearization clear.
[B] [A]
When P-3 is selected.
Put the weight.
Confirm the stability
mark lighting on.
