Minebea CSD-904-EX User Manual

III
② Installation
Warning
Each dimensions of the instrument and required dimensions for the environmental spaces are as follows:
Side shape when the AC cable, the external control input plug or load cell connecting plug is attached.
Side shape when the BCD plug is attached.
● When installing the instrument, install as referring to the following figures and secure the space around the instrument.
Unit：mm
Front Side
Rear
Unit：mm
(55)
(48.5)
(50.3)
(
45.3
)
187 0
＋1
92
Panel cut size
0
＋1
192
96
141
(11)
20.2
186
91
