IV
③ Applicable environment
Warning: The instrument may subject to use in a highly humid area or in full of powder dust.
In such a case, use the instrument by inserting the panel mount gasket attached between the
control panel
(cabinet) and the main body.
By inserting the panel mount gasket, the front panel section becomes IP65 (International Protection Code) or
equivalent in dust-proof and water-proof construction.
Panel mounting attachment
Screw
Control board (Cabinet)
Panel mounting gasket
(Dust proof・Water proof)
To Next Page
