Items Function No.
Setting value
Contents
Width of comparator
hysteresis data
F-25
00～99
●00
Unit : 1D
00 : Hysteresis OFF
●0
Stream (outputs synchronizing with the
display frequency.)
BCD output operation
mode
F-30
1
Synchronizes with the print.
(Synchronize with the key, the external
control input or the automatic print.)
●0 Display interlock
1 Gross value
2 Net value
3 Tare weight value
4 Accumulation total amount
BCD output target F-31
5 Accumulation frequency
BCD output logic F-32
0000～1111
●0000
0：Negative logic
1：Positive logic
10
0
digit : Data output logic
(Load data and decimal point)
10
1
digit : Polarity logic
10
2
digit : Flag logic(ERROR, OVER, Stable,
Gross)
10
3
digit : P.C.(Print command) logic
0 125 ms
BCD P.C. (Print
Command)
width
F-33
●1 25 ms
●0 Command mode
1
Stream mode
(Output synchronizes with display
frequency.)
RS-232C operating mode F-40
2
Synchronizes with print
(Output synchronizing with the key, an
external control input or automatic print.)
●0 Gross value
1 Net value RS-232C output target
F-41
(Effective at
F-40 = 1 or 2)
2 Load display data with condition
RS-232C/422/485
specification for
communication
F-42 ●13020
Data bit length
10
0
digit : ●0＝7bit, 1＝8bit
Parity
10
1
digit : 0＝No parity, 1＝Even parity
●2＝Odd parity
Stop bit
10
2
digit : ●0＝1bit, 1＝2bit
Baud rate
10
3
digit : 0＝1 200 bps, 1＝2 400 bps,
2＝4 800 bps, ●3＝9 600 bps,
Terminator
10
4
digit : 0＝CR, ●1＝CR＋LF
RS-422/485
Address setting
F-43
00～31
●00
●0 RS-422
Changeover of RS-422/485
F-44
1 RS-485
RS-485 reply data delay
time
F-45
0～9
●1
Unit : 0.1 s
● has been set as default.
