40
Items Function No.
Setting
value
Contents
0 Nothing
RS-232C/422/485
transmission data decimal
point existence
F-46
1 Existing
0 OFF
1 Manual additive only
2 Manual additive both /
3 Auto additive only
Accumulation function
operating conditions
F-50
4 Auto additive both /
Setting of accumulation
prohibition belt
F-51
0099
05
Unit : 1D
00 : Accumulation when stability is detected
always
00 Operation OFF
1 The same operation as the key
2 The same operation as the key
3 The same operation as the key
4 The same operation as the key
5 The same operation as the key
6 The same operation as the key
7 The same operation as the key
8 The same operation as the key
9
Display net value
(Effective only in the measurement mode.)
External control input
INPUT1 operation setting
F-60
10
Display accumulated value
(Effective only in the measurement mode.)
External control input
INPUT2 operation setting
F-61 It is optional as well as F-60.
External control input
INPUT3 operation setting
F-62 It is optional as well as F-60.
External control input
INPUT4 operation setting
F-63 It is optional as well as F-60.
External control input
INPUT5 operation setting
F-64 It is optional as well as F-60.
External control input
INPUT6 operation setting
F-65 It is optional as well as F-60.
External control input
INPUT7 operation setting
F-66 It is optional as well as F-60.
Memory clear F-99 Set the function content is returned to setting default.
has been set as default.
