13-2-5. Width of P.C.(Print command)
The width of print command is selected by the setting of function F-33.
The width of print command is selected from “125 ms” or “25 ms”.
Default has selected “25 ms”.
13-2-6. Pin configuration of BCD output connector
Pin No. Input/Output BCD code Pin No. Input/Output BCD code
1 Output 1 26 Output 1
2 Output 2 27 Output 2
3 Output 4 28 Output 4
4 Output 8
10
0
29 Output 8
10
5
5 Output 1 30 Output 1
6 Output 2 31 Output 2
7 Output 4 32 Output 4
8 Output 8
10
1
33 Output 8
10
6
9 Output 1 34 － N.C.
10 Output 2 35 － N.C.
11 Output 4 36 － N.C.
12 Output 8
10
2
37 － N.C.
13 Output 1 38 Output Decimal point 10
1
14 Output 2 39 Output Decimal point 10
2
15 Output 4 40 Output Decimal point 10
3
16 Output 8
10
3
41 － N.C.
17 Output 1 42 Output Stable
18 Output 2 43 － N.C.
19 Output 4 44 Output Gross value
20 Output 8
10
4
45 Input BCD-ENABLE
21 － N.C. 46 Output OVER
22 － N.C. 47 Output P.C.
23 Output POL. 48 Output P.C.
24 － COM. 49 Input HOLD
25 Output ERROR 50 － COM.
Suitable plug : 57-30500 (DDK)
● The print command becomes unstable in the starting period because of converting the BCD data.
Please read correct BCD data according to the timing of the falling down of the print command.
● Don’t connect with N.C. pin.
● The external control input COM. (two pins) and the COM. for BCD output are common.
● The internal circuit and photo-coupler is insulated.
● In other than the measurement mode, the output will become OFF.
