Minebea CSD-904-EX - Page 94

83
2 4 6 8 10 12 14
@ 0 0 9 9 ＋ 0 . 1 2 3 Terminator
2 4 6 8 10 12 14
@ 0 0 9 9 ＋ O L Terminator
2 4 6 8 10 12 14
@ 0 0 9 9 ― O L Terminator
② When the setting of function F-41 is set with “Load display data with condition”
2 4 6 8 10 12 14 16
C1 C2 , C3 C4 , C5 C6 C7 C8 C9 C10 C11 C12 C13 C14 C15 Terminator
Header 1 Header 2 Sign Load data 8 digit Unit
C1 C2 Contents C3 C4 Contents C5 Contents C6 C7 C8 C9 C10 C11 C12 C13 C14 C15 Contents
O L Overload N T Net ＋ Plus 1 2 3 g g
S T Stable G S Gross － Minus 0 . 1 2 3 k g kg
U S Unstable O L t ton
l b Pound
Header 1
Header 2
Sign
Load data 8 digits
Unit
