Configuration
Command Menu - FA-300 Config - Features
7 “Aux. disconnect” disconnects
Common Alarm Relay and
Common Supervisory Relay
[ ] ENABLE
[X] DISABLE->Default
"Aux Disconnect"
disconnects alarm
relay
If enabled, the Common Alarm
Relay and the Common
Supervisory Relay, in addition
to the Auxiliary Alarm Relay,
are disconnected when you
select “Aux Disconnect” (see
page 75). The PR-300 will not
transmit a supervisory or alarm
event.
If disabled, selecting “Aux
Disconnect” (see page 75) has
no effect on the Common Alarm
Relay, the Common
Supervisory Relay, and the PR-
300.
Command Menu - FA-300 Config - Features
8 Auto Signal Silence Timer
[X] DISABLE->Default
[ ] 5 Min
[ ] 10 Min
[ ] 15 Min
[ ] 20 Min
[ ] 30 Min
Signal silence
Use this function to determine
the time period for which the
indicating circuits sound before
they are automatically silenced.
Command Menu - FA-300 Config - Features
9 Number of Remote
Annunciators or smart relays
[X] NONE->Default
[ ] 1
[ ] 2
[ ] 3
[ ] 4
[ ] 5
[ ] 6
Remote Annunciators
Use this function to select the
number of Remote
Annunciators. Any combination
of Remote Annunciators or
smart relays can be used as
long as the total number does
not exceed 6. The
Annunciators’ addresses
should be without gaps and in
sequence.
Command Menu - FA-300 Config - Features
10 Silence Alarm transmit
[X] DISABLE ->Def
[ ] ENABLE
Alarm transmit
affected by signal
silence
If disabled, the SIGNAL
SILENCE button does not
silence the Auxiliary Alarm
Relay, but it does silence the
indicating circuits. If enabled,
the SIGNAL SILENCE button
silences the Auxiliary Alarm
Relay and the indicating
circuits. See "9.2.2 SIGNAL
SILENCE Button" on page 44.
Command Menu - FA-300 Config - Features
11 AC power fail delay timer
[X] NONE ->Default
[ ] 1 HRS
[ ] 2 HRS
[ ] 3 HRS
Use this function to delay the
AC power fail trouble for the
programmed time period. If
disabled, the AC power fail is
reported right away.
Command Menu - FA-300 Config - Features
12 Common Supervisory Relay
[X] ENABLE ->Default
[ ] DISABLE
Supervisory relay used
as alarm relay
If enabled, the Common
Supervisory Relay behaves as
a common alarm relay. If
disabled, it behaves as a
common supervisory relay.
Table 7 Feature Config menu
Feature Default
Name in the
FA-300
Configuration Utility
Description
Aux Dis,Dis Alm&Spv
[X] DISABLE
Auto Sig-Sil. Timer
[X] DISABLE
No. of Remote Annun.
[X] NONE
Alm. Xmit-Sil.
[X] DISABLE
AC Pwr Fail Dly Tmr.
[X] NONE
Common Supv. Relay
[X] ENABLE
