Mircom FA-301-12DDR User Manual

60
Configuration
Command Menu - FA-300 Config
11.4.3 Opt Zone
Command Menu --> FA-300 Config
11.4.4 Correlation
Command Menu --> FA-300 Config
11.4.5 Inp Zone Label
Command Menu - FA-300 Config - Opt. Zone
1. Type (Indicating Circuits)
4.
[X] SIL-ABLE->Default
[ ] NON SIL-ABLE
[ ] SIL-ABLE STR
[ ] NON-SIL STR
Use this menu to select the
circuit type of each
indicating circuit. See
"9.4.10 Indicating (Signal)
Circuit Types" on page 47.
Command Menu - FA-300 Config -
Correlation
1.Correlation
12.
[X] NAC-1 ->Default
[X] NAC-2 ->Default
[X] NAC-3 ->Default
[X] NAC-4 ->Default
Use this menu to correlate
initiating circuits to
indicating circuits. By
default all the initiating
circuits are correlated to all
the indicating circuits.
1 NAC-1
2 NAC-2
3 NAC-3
4 NAC-4
Indicating Zone
NAC-1 Type
[X] SIL-ABLE
NAC-4 Type
[X] SIL-ABLE
Zone-1 Corr.
[X] NAC-1
Zone-12 Corr.
[X] NAC-1
1 Zone-1
2 Zone-2
--
--
Initiating Zone
12 Zone12
