Configuration
Use the keypad described below for entering a message.
Command Menu --> FA-300 Config
11.4.6 Opt Zone Label
Follow the instructions below to enter a message.
Command Menu - FA-300 Config - Ipt. Zone
Label
1.Initiating zone label
12.
[Zone-1 ]->Default
[Zone-12 ]->Default
KEYPAD TRANSLATION AS MARKED ON THE KEYS
SEQ refers to the number of times the key must be pressed
to display the number or letter.
KEY SEQ 1 2 3 4 KEY SEQ 1 2 3 4
--------------------------------------
Key #1 1
Key #2 2 A B C Key #3 3 D E F
Key #4 4 G H I Key #5 5 J K L
Key #6 6 M N O Key #7 7 P R S
Key #8 8 T U V Key #9 9 W X Y
Key #0 0 Q Z Key * Backspace
Key # Forward
Press the ENTER button to input the message.
Command Menu - FA-300 Config - Opt. Zone
Label
1.Indicating zone label
4.
[NAC-1 ]->Default
[NAC-4 ]->Default
KEYPAD TRANSLATION AS MARKED ON THE KEYS
SEQ refers to the number of times the key must be pressed
to display the number or letter.
KEY SEQ 1 2 3 4 KEY SEQ 1 2 3 4
--------------------------------------
Key #1 1
Key #2 2 A B C Key #3 3 D E F
Key #4 4 G H I Key #5 5 J K L
Key #6 6 M N O Key #7 7 P R S
Key #8 8 T U V Key #9 9 W X Y
Key #0 0 Q Z Key * Backspace
Key # Forward
Press the ENTER button to input the message.
Zone-1 Label
Zone-1
Zone-12 Label
Zone-12
1 NAC-1
2 NAC-2
3 NAC-3
4 NAC-4
Indicating Zone
NAC-1 Label
NAC-1
NAC-4 Label
NAC-4
