Enclosure Installation
Version 5.4 TX3 Telephone Access System Installation and Operation Manual 25
LT-969 Copyright 2019
5. Place the screw halfway into the wall into the marked hole location using
the supplied screw.
6. Hang the Trim Ring onto the top screw.
7. Screw the lower two screw at the bottom of the trim ring halfway into the
wall.
8. Tighten the two screws into place.
9. Insert the universal enclosure with the rain hood inside the trim ring.
10. Secure the universal enclosure into the trim ring using the supplied four
screws as shown in figure 2.
To surface mount the Universal enclosure
1. Find a suitable location for the Universal enclosure over a wall stud.
2. Using the Universal enclosure as a template, mark the two mounting hole
locations as indicated in figure 1. Ensure that at least one side is over a
wall stud.
3. Remove the enclosure and place the screws halfway into the marked hole
location and wall stud using the supplied screws.
4. Place the Universal enclosure onto the two screws.
5. Screw the two side screws of the Universal enclosure halfway into the
wall.
6. Tighten all four screws into place.
Note: The enclosure can also be mounted directly onto the drywall using
anchors.
To install the Universal enclosure with the Flush Trim Ring to the
back wall
1. Find a suitable location for the enclosure. Using the enclosure as a
template trace an opening in the wall for the cut out.
2. Cut an opening in the wall.
3. Using the semi-flush trim ring as a template, insert the trim ring into the
wall cut out and mark the top two mounting hole locations as shown in
figure 2.
4. Place the screws halfway into the wall into the marked hole location using
the supplied screws.
