26 TX3 Telephone Access System Installation and Operation Manual Version 5.4
LT-969 Copyright 2019
Enclosure Installation
5. Place the Trim Ring onto the two screws.
6. Screw the lower two screws at the bottom of the trim ring halfway into the
wall.
7. Remove the screws and trim ring.
8. Place the universal enclosure with the rain hood, inside the trim ring and
insert into the wall cut out.
9. Tighten all four screws into place.
To install the Universal enclosure without the Flush Trim Ring to the
back wall
1. Using the semi-flush trim ring as a template, insert the Universal
enclosure into the wall cut out and mark the top two mounting hole
locations as indicated in figure 2.
2. Place the screws halfway into the wall into the marked hole location using
the supplied screws.
3. Place the Universal enclosure onto the two screws.
4. Screw the lower two screws at the bottom of the Universal enclosure
halfway into the wall.
5. Tighten all four screws into place.
