Installation
114
Mitel 470 as of R4.1
syd-0585/1.2 – R4.1 – 08.2016
Prefabricated system cable 12 x RJ45
The cable is 6 m long and, at one extremity, has 12 RJ45 connectors for the interfaces
on the front panel. Two of them have 4 cores; the others, 2 cores. This means the ca-
ble is suitable for connecting the following interfaces:
• 2 network interfaces BRI-T or 2 terminal interfaces BRI-S or a combination thereof.
• 10 terminal interfaces (DSI, FXS) or a combination thereof.
Note:
This cable cannot be used to connect PRI and Ethernet interfaces (see also "Connection of PRI
primary rate interface", page 121 and "Connection of Ethernet interfaces", page 157).
Tip
Use standard commercial connecting cables not just for the PRI and Ethernet interfaces but
also for connecting the BRI-T interfaces.
3
white
2
4x.1a
green 5 x.1b
turquoise 3 x.2a
violet 6 x.2b
4
white 1 x.3a
brown 2 x.3b
turquoise 7 x.4a
violet 8 x.4b
5
white
3
4x.1a
grey 5 x.1b
turquoise 3 x.2a
violet 6 x.2b
6
red 1 x.3a
blue 2 x.3b
turquoise 7 x.4a
violet 8 x.4b
7
red
4
4x.1a
orange 5 x.1b
turquoise 3 x.2a
violet 6 x.2b
8
red 1 x.3a
green 2 x.3b
turquoise 7 x.4a
violet 8 x.4b
Stranded
element
Core colour
Cable desig-
nation
RJ45 Port
Pin Two-wire connection
