1 INTRODUCTION
1.3 Environment
11
1
HK-ST/HK-RT (3.5 kW - 7.0 kW) series
The rating plate indicates the characteristic values for when the torque has been increased by changing the servo amplifier.
For the characteristics in combination with each servo amplifier, refer to "Servo amplifier/motor combinations" in the following
manual.
MR-J5 User's Manual (Hardware)
1.3 Environment
*1 Do not use in an environment where there is exposure to oil mist, oil, and water.
*2 Refer to the following for restrictions on the ambient temperature.
Page 117 Derating
Page 154 Derating
Page 194 Derating
*3 Refer to the following for restrictions on using this product at an altitude exceeding 1000 m and up to 2000 m.
Page 117 Derating
Page 154 Derating
Page 194 Derating
Condition Operation Transportation/storage
Ambient temperature 0 ˚C to 60 ˚C (non-freezing)
*2
-15 ˚C to 70 ˚C (non-freezing)
Ambient humidity 10 %RH to 90 %RH (non-condensing) 10 %RH to 90 %RH (non-condensing)
Ambience
*1
Indoors (no direct sunlight); no corrosive gas, inflammable gas, oil mist, dust, nor high magnetic field
Altitude 2000 m or less
*3
Vibration resistance Refer to the following.
Page 101 Standard specifications
Page 143 Standard specifications
Page 189 Standard specifications
External magnetic field 10 mT or less
TOKYO 100-8310 , JAPAN
3AC
SERVO MOTEUR AC
AC SERVO MOTOR
CONT
mV/min
-1
40°C
SER.
V
A
r/min 0-
Hz
IEC60034-1
IEC61800-3
HK-ST102W
102
7.0
1kW
5.2
F
1500
58
125
98
IP67
M00001234 194
MADE IN JAPAN
FABRIQUÉ AU JAPON
P.F.
%
CI.
Model
Input power, rated voltage, rated current, and rated output
Mass and insulation class
Rated speed
Induced voltage constant and maximum ambient temperature
Power factor and IP rating
Serial number
Country of origin
Manufacturer
