9 COMPLIANCE WITH EACH REGION
9.2 Compliance with UL/CSA standard
Selection example of wires
To comply with the UL/CSA standard, use UL-approved copper wires rated at 75 ˚C for wiring.
The following table shows wires [AWG] rated at 75 .
HK-KT series
*1 This is used for fabricating extension cables. Use options when wiring the servo motor.
HK-ST series
Rotary servo motor Wire [AWG]
U/V/W/ B1/B2
HK-KT053W 14
*1
16
*1
HK-KT13W
HK-KT1M3W
HK-KT13UW
HK-KT23W
HK-KT43W
HK-KT63W
HK-KT23UW
HK-KT43UW
HK-KT7M3W
HK-KT103W
HK-KT7M3UW
HK-KT103UW
HK-KT153W
HK-KT203W
HK-KT202W
HK-KT434W
HK-KT634W
HK-KT7M34W
HK-KT1034W
HK-KT1534W
HK-KT2034W
HK-KT2024W
Rotary servo motor Wire [AWG]
U/V/W/ B1/B2
HK-ST52W 14 16
HK-ST102W
HK-ST172W
HK-ST202AW
HK-ST302W
HK-ST202W
HK-ST352W 12
HK-ST502W 8
HK-ST702W 8
HK-ST524W 14
HK-ST1024W
HK-ST1724W
HK-ST2024AW
HK-ST3024W
HK-ST2024W
HK-ST3524W
HK-ST5024W 12
HK-ST7024W
