5 WIRING OPTION
5.2 Motor cable/connector sets
77
5
MR-AEPB1CBL_M-_-_/MR-AEP1CBL_M-_-_
These cables are motor cables for the HK-KT series rotary servo motors.
Model
The following describes what each block of a model name indicates. Not all combinations of the symbols are available.
Connecting the servo amplifier and rotary servo motor
*1 This connection is for the MR-J5 3-axis servo amplifier.
*2 Refer to the following for connection of the power connector.
Page 35 Wiring
AEPB1 BCL - LA1 -2M
L
H
22
5
10
5
10
A1
A2
A5
B
MR -
Flex type
Symbol Flex type
Standard (for fixed parts)
High flex life (for moving parts)
Outlet direction
Symbol
Outlet direction
Load-side lead
Opposite to load-side lead
Cable length
Symbol Cable length [m]
Electromagnetic brake cable
Electromagnetic brake cable
Symbol
××
Vertical lead
MR-AEPB1CBL_M-_-_
MR-AEP1CBL_M-_-_
*2
(1) (2)
*1
CN2B
CN2C
CN2A
CN2
MR-J5 1-axis
servo amplifier
MR-J5 multi-axis
servo amplifier
Rotary servo motor
