5 WIRING OPTION
5.1 Cable/connector sets
61
5
(9) Motor cables
(Dual cable type/
junction
connection type)
Motor side: IP65
Junction side:
IP20
For the HK-KT/
HK-RT (1.0 kW -
2.0 kW) series
With
electromagnetic
brake cable
Standard
(for fixed
parts)
0.3 m MR-AEPB2J10CBL03M-
A1-L
Refer to the following for details.
Page 71 MR-AEPB2J10CBL03M-_-L/MR-
AEP2J10CBL03M-_-L
(10) For the HK-KT/
HK-RT (1.0 kW -
2.0 kW) series
Without
electromagnetic
brake cable
Standard
(for fixed
parts)
0.3 m MR-AEP2J10CBL03M-
A1-L
Refer to the following for details.
Page 71 MR-AEPB2J10CBL03M-_-L/MR-
AEP2J10CBL03M-_-L
(11) For the HK-KT/
HK-RT (1.0 kW -
2.0 kW) series
With
electromagnetic
brake cable
Standard
(for fixed
parts)
0.3 m MR-AEPB2J10CBL03M-
A2-L
Refer to the following for details.
Page 71 MR-AEPB2J10CBL03M-_-L/MR-
AEP2J10CBL03M-_-L
(12) For the HK-KT/
HK-RT (1.0 kW -
2.0 kW) series
Without
electromagnetic
brake cable
Standard
(for fixed
parts)
0.3 m MR-AEP2J10CBL03M-
A2-L
Refer to the following for details.
Page 71 MR-AEPB2J10CBL03M-_-L/MR-
AEP2J10CBL03M-_-L
(13) Encoder cable
Junction side:
IP20
For the HK-KT/
HK-RT (1.0 kW -
2.0 kW) series
Standard
(for fixed
parts)
20 m MR-AEKCBL20M-L
Refer to the following for details.
Page 80 MR-AEKCBL_M-_
30 m MR-AEKCBL30M-L
(14) High flex
life
(for moving
parts)
20 m MR-AEKCBL20M-H
30 m MR-AEKCBL30M-H
40 m MR-AEKCBL40M-H
50 m MR-AEKCBL50M-H
(15) Encoder
connector set
Junction side:
IP20
For the HK-KT/
HK-RT (1.0 kW -
2.0 kW) series
MR-ECNM
Refer to the following for details.
Page 80 MR-AEKCBL_M-_
No. Product name Application Flex type Cable
length
Model Description/IP rating/Cable direction
IP65
IP20
Load-side lead
IP65
IP20
Load-side lead
IP65
IP20
Opposite to load-side lead
IP65
IP20
Opposite to load-side lead
IP20
IP20
