4G1 ENGINE (E–W) – Specifications
11A-1-3
PWEE9520
E
Nov. 1995Mitsubishi Motors Corporation
REWORK DIMENSIONS
Item Standard Limit
Cylinder head and valves
Cylinder head oversize valve guide
hole diameter mm
SOHC 12-VALVE 0.05 O. S. 12.04012.058
hole diameter mm
0.25 O. S. 12.24012.258
0.50 O. S. 12.49012.508
SOHC 16-VALVE 0.05 O. S. 10.55010.568
0.25 O. S. 10.75010.768
0.50 O. S. 11.00011.018
DOHC 0.05 O. S. 10.55010.568
0.25 O. S. 10.75010.768
0.50 O. S. 11.00011.018
DOHC GDI 0.05 O. S. 10.61010.620
0.25 O. S. 10.81010.820
0.50 O. S. 11.06011.070
Oversize valve seat
ring hole diameter
SOHC
12 VALVE
Intake (primary) 0.3 O. S. 27.30027.325
ring hole diameter
mm
12-VALVE
0.6 O. S. 27.60027.625
mm
Intake (secondary) 0.3 O. S. 32.30032.325
0.6 O. S. 32.60032.625
Exhaust 0.3 O. S. 35.30035.325
0.6 O. S. 35.60035.625
SOHC
16 VALVE
Intake 0.3 O. S. 28.30028.321
16-VALVE
<4G13>
0.6 O. S. 28.60028.621
<4G13>
Exhaust 0.3 O. S. 26.30026.321
0.6 O. S. 26.60026.621
SOHC
16 VALVE
Intake 0.3 O. S. 30.30030.321
16-VALVE
<4G18>
0.6 O. S. 30.60030.621
<4G18>
Exhaust 0.3 O. S. 28.30028.321
0.6 O. S. 28.60028.621
DOHC Intake 0.3 O. S. 31.30031.325
0.6 O. S. 31.60031.625
Exhaust 0.3 O. S. 27.80027.825
0.6 O. S. 28.10028.125
PWEE9520-E
E
Feb. 2001Mitsubishi Motors Corporation Revised
