Mitsubishi 4G1 series

4G1 ENGINE (E-W) -
Oil Pump and Oil Pan
11A-10-1
PWEE9520
E
Nov. 1995Mitsubishi Motors Corporation
10. OIL PUMP AND OIL PAN
REMOVAL AND INSTALLATION <EXCEPT GDI (FRONT WHEEL DRIVE)>
11
1
12
14
13
16
15
10
9
8
6
5
7
2
3
10 Nm
14 Nm
44 Nm
7Nm
4
39 Nm
23 Nm
Apply engine oil to all
moving parts before
installation.
24 Nm
23 Nm
17
19 Nm
Removal steps
"
E
A
1. Oil filter
2. Drain plug
"
D
A
3. Gasket
4. Transmission stay (cast metal)
5. Transmission stay (sheet metal)
A
A
""
C
A
6. Oil pan
7. Oil screen
8. Gasket
9. Relief valve
10. Relief valve spring
11. Relief plunger
"
B
A
12. Front oil seal
"
A
A
13. Front case
14. O-ring
15. Oil pump cover
16. Oil pump outer rotor
17. Oil pump inner rotor
PWEE9520-D
E
Aug. 2000Mitsubishi Motors Corporation Revised
