Mitsubishi 4G1 series General Information

4G1 ENGINE (E–W) – Specifications
11A-1-4
PWEE9520
E
Nov. 1995Mitsubishi Motors Corporation
TORQUE SPECIFICATIONS
Item Nm
Alternator and ignition system
Water pump pulley bolt 9
Alternator brace bolt (alternator side) 22
Alternator brace bolt (tightened with water pump) 23
Alternator pivot bolt 44
Oil level gauge guide bolt (Flange) 23
Oil level gauge guide bolt (Washer) 19
Crankshaft bolt (M12) 125
Crankshaft bolt (M14) 181
Spark plug 25
Distributor bolt 11
Ignition coil bolt 10
Ignition failure sensor bolt 5
Camshaft position sensor bolt 9
Camshaft position sensor support bolt 13
Camshaft position sensing cylinder bolt 21
Timing belt
Timing belt cover bolt 11
Timing belt tensioner bolt 23
Crankshaft angle sensor bolt 9
Bracket bolt 21
Engine support bracket bolt (M8) 21
Engine support bracket bolt, nut (M10) 35
Idler pulley bolt 35
Camshaft sprocket bolt 88
Fuel and emission control system
Vacuum pipe & hose bolt 9
Delivery pipe bolt 11
Fuel pressure regulator bolt 9
Throttle body bolt 18
Hose clamp bolt 10
Fuel pump bolt (SOHC 12-VALVE–CARBURETOR) 12
Fuel pump bolt (SOHC 16-VALVE–CARBURETOR) 19
Breather tube clamp bolt 22
Carburetor bolt 17
Air temperature sensor 13
Cover bolt (Except M8 × 16) 12
PWEE9520-G
E
Apr. 2003Mitsubishi Motors Corporation Revised
