2MSB–02E11–505
3. Details:
M12 CRANKSHAFT BOLT
In order to prevent the crankshaft bolt from loosening and thereby improve reliability, an increased
tightening torque has been established as follows:
<Tightening torque>
Tightening torque
urren
orque
ew
orque
ype
125 N@m 132 N@m 3
132 N@m + (35 to 55°)
Caution: Stop tightening and never tighten the bolt any more
if a torque of 206 N@m is reached during additional tightening
to an angle within the specified range.
4
Applicable vehicle models
Vehicle model (code) Type Remarks
LANCER (CJ1A, CJ2A) 3 Crankshaft with casting pulley
4 Crankshaft with steel plate pulley
LANCER (CS1A, CS2A, CS3A) 4 Crankshaft with steel plate pulley
SPACE STAR (DG1A, DG3A) 3 Crankshaft with casting pulley
4 Crankshaft with steel plate pulley
