4G1 ENGINE (E-W) -
Intake Manifold and Throttle Body (GDI)
11A-5a-2
PWEE9520
E
Nov. 1995Mitsubishi Motors Corporation
REMOVAL SERVICE POINT
A
A
"
INTAKE MANIFOLD REMOVAL
Disconnect the fuel pressure sensor connectors.
INSTALLATION SERVICE POINTS
"
A
A
INTAKE MANIFOLD INSTALLATION
After installing the intake manifold, connect the fuel pressure
sensor connectors.
"
B
A
INTAKE MANIFOLD STAY INSTALLATION
Ensure that the intake manifold stay is in close contact with
the intake manifold and the cylinder block boss. After that,
tighten the bolts to the specified torque.
PWEE9520-D
