Mitsubishi 4G1 series

4G1 ENGINE (E-W) -
Exhaust Manifold (GDI)
11A-5b-1
PWEE9520
E
Nov. 1995Mitsubishi Motors Corporation
EXHAUST MANIFOLD (GDI)
REMOVAL AND INSTALLATION
30 Nm
3
18 Nm
7
4
2
6
29 Nm
5
35 Nm
35 Nm
1
44 Nm
Removal steps
1. Oxygen sensor
2. Exhaust manifold cover
3. Exhaust manifold bracket B
4. Exhaust manifold
5. Exhaust manifold gasket
6. Exhaust manifold bracket A
7. Power plant stay, left
PWEE9520-D
E
Aug. 2000Mitsubishi Motors Corporation Added
