Mitsubishi 4G1 series General Information

4G1 ENGINE (E-W) -
Oil Pump and Oil Pan
11A-10-1a
PWEE9520
E
Nov. 1995Mitsubishi Motors Corporation
REMOVAL AND INSTALLATION <EXCEPT GDI (REAR WHEEL DRIVE)>
11
1
12
14
13
16
15
10
9
8
6
5
7
2
3
10 Nm
14 Nm
44 Nm
7Nm
4
39 Nm
23 Nm
24 Nm
Apply engine oil to all
moving parts before
installation.
19 Nm
Removal steps
"
E
A
1. Oil filter
2. Drain plug
"
D
A
3. Gasket
4. Transmission stay
A
A
""
C
A
5. Oil pan
6. Oil screen
7. Gasket
8. Relief valve
9. Relief valve spring
10. Relief plunger
"
B
A
11. Front oil seal
"
A
A
12. Front case
13. O-ring
14. Oil pump cover
15. Oil pump outer rotor
16. Oil pump inner rotor
PWEE9520-D
E
Aug. 2000Mitsubishi Motors Corporation Added
