Mitsubishi 4G1 series General Information

4G1 ENGINE (E–W) – Intake and Exhaust Manifolds
11A-7-2c
PWEE9520
E
Nov. 1995Mitsubishi Motors Corporation
REMOVAL AND INSTALLATION <SOHC 16-VALVE–MPI – FRONT WHEEL DRIVE
(FROM 2001 model for Europe)>
44 Nm
8
14
30 Nm
9
35 Nm
3
31 Nm
17 Nm
49 Nm
2
6
5
1
5 Nm
9 Nm
17 Nm
12
18 Nm
10
30 Nm
11
13
9 Nm
35 Nm
35 Nm
30 Nm
19 Nm
7
4
17 Nm
15
16
35 Nm
Removal steps
1. Boost sensor
2. Engine hanger
3. Power plant stay, right
(From 2004 model)
4. Intake manifold stay
5. Intake manifold
6. Intake manifold gasket
7. Solenoid valve assembly
8. Solenoid valve assembly
9. Oxygen sensor
10. Engine hanger
11. Exhaust manifold cover
12. Exhaust monifold bracket B
13. Exhaust manifold
14. Exhaust manifold gasket
15. Exhaust manifold bracket A
(Up to 2003 model)
16. Power plant stay, left
(From 2004 model)
PWEE9520-G
E
Apr. 2003Mitsubishi Motors Corporation Revised
