Mitsubishi FX1N Series Programming Manual

FX Series Programmable Controlers Applied Instructions 5
5-196
*A500 + A5NR settings
*Note:
The time settings should be set as low as possible to avoid problems during a communication
failure. The inverter will continue to run during the set time which may cause equipment
damage or raise a safety issue. Please turn the inverter Off when communication problems
are encountered.
Parameter
number
Name Setting range
Setting
increment
Inverter
station
No.
SettingforcommstoPLC
331
Inverter station
No.
0~31 1 0
Align setting with station
number in the sequence
program
332 Comms speed
3,6,12,24,48,9
6,192
196
Normally select 192.
If high speed processing in
PLC use 96 or 48
333 Stop bit length
0,1(8bit)
10,11 (7bit)
11Select10
334
Parity check
yes/no
0,1,2 1 2 Select 2
335
Comms retry
count
0~10, 9999 1 1
During trial run select 9999
and perform adjustment.
During actual operation
select value in accordance
with system specifications
336
Comms check
time interval
0~999.8, 9999 0.1 0
337*
Wait time
setting
0~150ms,
9999
1ms 9999
While default value 0 is
selected, communications
are disabled.
Select 9999, perform
adjustment, then select
optimal value. See Note
below.
338
Operation
command write
0,1 1 0
Select either value in
accordance to system
specifications
339
Speed
command write
0,1 1 0
Select either value in
accordance to system
specifications
340
Link start mode
selection
0,1,2 1 0
Select either value in
accordance to system
specifications
341
CR/LF yes/no
selection
0,1,2 1 1 Select 1 CR only
342
EEPROM write
selection
0: write to
EEPROM
1: write to
RAM
10
Select either value in
accordance to system
specifications

Mitsubishi FX1N Series Specifications

General

Programming Language	Ladder Logic
Output Type	Relay, Transistor
Operating Temperature	0 to 55°C
Power Supply	100-240V AC or 24V DC
Program Capacity	8K steps
Communication Ports	RS-422
Data Memory	8000 words
High-speed Counters	Up to 6 channels
Expansion Modules	Available
Pulse Output	2 points
